ART 167 - PN25 Cast Iron Swing Check Valve
Description
PN25 Cast Iron Swing Check Valve
Features
- Flange Mounting PN25 Only
- Flange conforms to BS EN1092 PN25
- BS5153 (BS EN 558-1 Series 21)
Object Data
1 Revision
Last Updated
20/10/2020
Available Software
BS1192:4
Compliant
BSB
Compliant
EPD
Available
Object metadata
- _AuthorRL
- _Authorized Bybimstore
- _Bim Spec Guid0
- _BS Bible Version16
- _Created Bywww.bimstore.co
- _Current Revision1
- _Distributed Bywww.bimstore.co
- _Object User Guidewww.bimstore.co/products/art-167-pn25-cast-iron-swing-check-valve/document/object-user-guide
- Accessibility Performancen/a
- Assembly CodeD20
- Asset TypeFixed
- B32 mm
- BIM Object NameAlbionValves_PipeAccessories_SwingCheckValve_ART167
- Circle Height127 mm
- Circle Width143 mm
- Classification NameUniclass2015
- Classification ValuePr_65_54_40_13
- Code Performancen/a
- ColorBlue
- Connection Size100 mm
- Constituentsn/a
- Created Bysales@albionvalvesuk.com
- Created On2020-08-19T09:00:00
- D254 mm
- DescriptionPN25 Cast Iron Swing Check Valve
- Documentation Certificateswww.albionvalvesuk.com/
- Documentation Installation Guidewww.albionvalvesuk.com/
- Documentation Literaturewww.albionvalvesuk.com/
- Documentation Maintenancewww.albionvalvesuk.com/
- Documentation Technicalwww.bimstore.co/products/art-167-pn25-cast-iron-swing-check-valve/document/technical-data-sheet
- Duration UnitYears
- Expected Life0
- F3 mm
- Featuresn/a
- FinishAlkyd Paint Coat Finish
- Flange D2156 mm
- Flange Dia254 mm
- Flange Holes Dia190 mm
- Graden/a
- H190 mm
- H132 mm
- H232 mm
- Half L178 mm
- H Dia200 mm
- Ifc Export AsIfcValve
- Ifc Export TypeIfcValveTypeEnum.CHECK
- KeynoteS
- L356 mm
- ManufacturerAlbion Valves
- Manufacturer NameAlbion Valves
- MaterialCast iron
- Max Pressure25 Bar
- ModelSwing Check Valve
- Model NumberDN100 - DN4"
- Model ReferenceSwing Check Valve
- NBS DescriptionCheck valves
- NBS Object NameAlbion Valves - Check valves
- NBS Office Master Tagn/a
- NBS Reference90-15-40/323
- Nominal Depth254 mm
- Nominal Height322 mm
- Nominal Length356 mm
- Nut Centre75 mm
- Nut Dia20 mm
- Nut Gap65 mm
- Nut Height5 mm
- Outside Diameter110 mm
- Production Year2020
- Referenced Standardn/a
- Replacement Costn/a
- Shapen/a
- SizeDN100 - DN4"
- Size DN100
- Spare Partsn/a
- Thread Inch4
- Thread Millimetre102 mm
- Type CommentsDN100 - DN4"
- Type NameSwing Check Valve
- URLwww.albionvalvesuk.com/
- Valve FinishIron, Cast, Blue
- Warranty DescriptionAgainst manufacturing defects.
- Warranty Duration Labor1
- Warranty Duration Parts1
- Warranty Duration UnitYears
- Warranty Guarantor Laborsales@albionvalvesuk.com
- Warranty Guarantor Partssales@albionvalvesuk.com
- Weight55.7 kgs
- Working Temperature-10°C to +230°C
We have more variations, please download the object to get them all.
Sustainability & Environmental Data
Self Certified Sustainability Data
This data is supplied and self certified by the manufacturer.
- Biogenic CO2e (A1-A3,B1-B5,C1-C4) 80 kg
- Total CO2e (Fossil) kg
- Manufacturing (A1-A3) kg
- Transport to Site (A4) kg
- On-Site Installation (A5) kg
- Use & Maintenance (B1-B5) kg
- End of Life (C1,C3,C4) kg
- Recycled Content %
- Recyclable Content %
- Re-use Potential %
- Energy Recovery Possibility %
- Water Use L
- Ozone Depletion Potential mg CFC-11eq
- Expiry-
Self Certified Sustainability Data
This data is supplied and self certified by the manufacturer.
- Biogenic CO2e (A1-A3,B1-B5,C1-C4) 114 kg
- Total CO2e (Fossil) kg
- Manufacturing (A1-A3) kg
- Transport to Site (A4) kg
- On-Site Installation (A5) kg
- Use & Maintenance (B1-B5) kg
- End of Life (C1,C3,C4) kg
- Recycled Content %
- Recyclable Content %
- Re-use Potential %
- Energy Recovery Possibility %
- Water Use L
- Ozone Depletion Potential mg CFC-11eq
- Expiry-
Self Certified Sustainability Data
This data is supplied and self certified by the manufacturer.
- Biogenic CO2e (A1-A3,B1-B5,C1-C4) 151 kg
- Total CO2e (Fossil) kg
- Manufacturing (A1-A3) kg
- Transport to Site (A4) kg
- On-Site Installation (A5) kg
- Use & Maintenance (B1-B5) kg
- End of Life (C1,C3,C4) kg
- Recycled Content %
- Recyclable Content %
- Re-use Potential %
- Energy Recovery Possibility %
- Water Use L
- Ozone Depletion Potential mg CFC-11eq
- Expiry-
Self Certified Sustainability Data
This data is supplied and self certified by the manufacturer.
- Biogenic CO2e (A1-A3,B1-B5,C1-C4) 225 kg
- Total CO2e (Fossil) kg
- Manufacturing (A1-A3) kg
- Transport to Site (A4) kg
- On-Site Installation (A5) kg
- Use & Maintenance (B1-B5) kg
- End of Life (C1,C3,C4) kg
- Recycled Content %
- Recyclable Content %
- Re-use Potential %
- Energy Recovery Possibility %
- Water Use L
- Ozone Depletion Potential mg CFC-11eq
- Expiry-
Self Certified Sustainability Data
This data is supplied and self certified by the manufacturer.
- Biogenic CO2e (A1-A3,B1-B5,C1-C4) 300 kg
- Total CO2e (Fossil) kg
- Manufacturing (A1-A3) kg
- Transport to Site (A4) kg
- On-Site Installation (A5) kg
- Use & Maintenance (B1-B5) kg
- End of Life (C1,C3,C4) kg
- Recycled Content %
- Recyclable Content %
- Re-use Potential %
- Energy Recovery Possibility %
- Water Use L
- Ozone Depletion Potential mg CFC-11eq
- Expiry-
Self Certified Sustainability Data
This data is supplied and self certified by the manufacturer.
- Biogenic CO2e (A1-A3,B1-B5,C1-C4) 469 kg
- Total CO2e (Fossil) kg
- Manufacturing (A1-A3) kg
- Transport to Site (A4) kg
- On-Site Installation (A5) kg
- Use & Maintenance (B1-B5) kg
- End of Life (C1,C3,C4) kg
- Recycled Content %
- Recyclable Content %
- Re-use Potential %
- Energy Recovery Possibility %
- Water Use L
- Ozone Depletion Potential mg CFC-11eq
- Expiry-
Self Certified Sustainability Data
This data is supplied and self certified by the manufacturer.
- Biogenic CO2e (A1-A3,B1-B5,C1-C4) 737 kg
- Total CO2e (Fossil) kg
- Manufacturing (A1-A3) kg
- Transport to Site (A4) kg
- On-Site Installation (A5) kg
- Use & Maintenance (B1-B5) kg
- End of Life (C1,C3,C4) kg
- Recycled Content %
- Recyclable Content %
- Re-use Potential %
- Energy Recovery Possibility %
- Water Use L
- Ozone Depletion Potential mg CFC-11eq
- Expiry-
Self Certified Sustainability Data
This data is supplied and self certified by the manufacturer.
- Biogenic CO2e (A1-A3,B1-B5,C1-C4) 1083 kg
- Total CO2e (Fossil) kg
- Manufacturing (A1-A3) kg
- Transport to Site (A4) kg
- On-Site Installation (A5) kg
- Use & Maintenance (B1-B5) kg
- End of Life (C1,C3,C4) kg
- Recycled Content %
- Recyclable Content %
- Re-use Potential %
- Energy Recovery Possibility %
- Water Use L
- Ozone Depletion Potential mg CFC-11eq
- Expiry-
Self Certified Sustainability Data
This data is supplied and self certified by the manufacturer.
- Biogenic CO2e (A1-A3,B1-B5,C1-C4) 1531 kg
- Total CO2e (Fossil) kg
- Manufacturing (A1-A3) kg
- Transport to Site (A4) kg
- On-Site Installation (A5) kg
- Use & Maintenance (B1-B5) kg
- End of Life (C1,C3,C4) kg
- Recycled Content %
- Recyclable Content %
- Re-use Potential %
- Energy Recovery Possibility %
- Water Use L
- Ozone Depletion Potential mg CFC-11eq
- Expiry-
