Billi Eco Sparkling with Gooseneck Multifunction Mixer Tap

by Billi

Download Add to collection

Description

The Eco Sparkling is the ultimate in modern design and filtered drinking water appliances delivering instant boiling and chilled filtered water, with the added luxury of sparkling water. Utilising underbench ice bank technology to enhance capacity and recovery, this is a perfect small office or residential system.

The Good Design Award Winning Multifunction Mixer tap complements the multifunctional approach of Billi’s Eco Sparkling range perfectly, negating the requirement for an additional domestic supply mixer tap while providing a sleek solution to dispensing filtered water.

Dispenser design	Gooseneck Multifunction Mixer Tap - 5 star WELS
Capacity	Up to 10 Persons
Underbench Size	C&S 410mm h x 255mm w x 420mm d \| Boiling 340mm h x 180mm w x 365mm d
Product Code	906000G
Water Combination	Boiling \| Chilled \| Sparkling

Object Data

1 Revision

Last Updated

16/05/2025

Available Software

BSB

Compliant

EPD

Not Available

_AuthorIH
_Authorized Bybimstore
_Bim Spec Guid0
_BS Bible Version17
_Created Byinfo@billi.com.au
_Current Revision0
_Distributed Bywww.bimstore.co/
_Object User Guidewww.bimstore.co/
Accessibility Performancen/a
Assembly CodeD2020
Asset TypeFixed
BIM Object NamePlumFixt_Assembly_Billi_EcoSparkling_G
Boiling Water Delivery90 cups per hour
CapacityUp to 10
Chilled Sparkling Water Delivery100 cups per hour
Classification NameUniclass2015
Classification ValuePr_40_70_23_42
Code Performancen/a
ColorBR - Brushed
Constituentsn/a
Created Byinfo@billi.com.au
Created On2025-02-20T09:00:00
Cups Per Hour NoteBased on a set volume of water being drawn every 30 seconds at an inlet temperature of average temperature 21°C. Each cup is equivalent to 170ml.
CW ConnectionYes
Default Elevation0 mm
DescriptionInstant boiling, chilled and sparkling filtered water system.
Dispenser DesignGooseneck Multifunction Mixer Tap
Documentation Certificateswww.billi.com.au/product/billi-eco-sparkling-with-gooseneck-multifunction-mixer-tap/
Documentation Installation Guidewww.billi.com.au/wp-content/uploads/2021/10/610013_Billi-Installation-Guide_Eco-Sparkling-8pp_Rev04.pdf
Documentation Literaturewww.billi.com.au/wp-content/uploads/2021/03/Billi-Oct-2024_Commercial-Brochure_Digital_FA.pdf
Documentation Maintenancewww.billi.com.au/product/billi-eco-sparkling-with-gooseneck-multifunction-mixer-tap/
Documentation Technicalwww.billi.com.au/wp-content/uploads/2024/10/6401_Billi_Comm-Datasheets-Eco-Sparkling-MMT_FA.pdf
Duration UnitYears
Expected Life0
FeaturesEnergy efficient. Adjustable chilled temperature. Adjustable sparkling level. HACCP certified. Eco intelligence technology. Ice Bank technology. BPA free.
Filter 1Filter : 5 Micron Fibron X
Filter 2Filter : 0.2 Micron Fibron XC
Filter 3Filter : HSD Fibron XT
Filter 4Filter : Sediment Only
Filter 5Filter : 0.2 Micron HF Sediment Only
Finishn/a
Graden/a
HW ConnectionNo
Ifc Export AsIfcValve
Ifc Export TypeIfcValveTypeEnum.FAUCET
KeynoteN13
ManufacturerBilli
Manufacturer NameBilli
Materialn/a
ModelBilli Eco Sparkling with Gooseneck Multifunction Mixer Tap
Model Number906000GBR
Model ReferenceBilli Eco Sparkling with Gooseneck Multifunction Mixer Tap
NBS DescriptionInstant boiling and cold water taps
NBS Noten/a
NBS Object NameBilli - Instant boiling and cold water taps
NBS Office Master Tagn/a
NBS Reference90-15-35/485
Nominal Depth503 mm
Nominal Height340 mm
Nominal Length181 mm
Power SupplyTwo standard 10 amp power outlets are required, located no further than 1000mm from the underbench unit. The system is supplied with two 1 metre flex cords and plugs
Production Year2025
Referenced Standardn/a
Replacement Costn/a
Shapen/a
Sizen/a
Spare Partsn/a
Tap MaterialBilli_Metal_Brushed
Type CommentsBilli Eco Sparkling with Gooseneck Multifunction Mixer Tap Brushed (906000GBR)
Type NameBilli Eco Sparkling with Gooseneck Multifunction Mixer Tap Brushed (906000GBR)
Underbench SizeC&S 410mm h x 255mm w x 420mm d Boiling 340mm h x 180mm w x 365mm d
Underbench Unit Depth503 mm
Underbench Unit Height340 mm
Underbench Unit Width181 mm
URLwww.billi.com.au/product/billi-eco-sparkling-with-gooseneck-multifunction-mixer-tap/
Vent ConnectionNo
Warranty DescriptionAll components of the drinking water systems are covered by a 24-month warranty.
Warranty Duration Labor2
Warranty Duration Parts2
Warranty Duration UnitYears
Warranty Guarantor Laborservice@billi.com.au
Warranty Guarantor Partsservice@billi.com.au
Waste ConnectionNo
Water TypeBoiling Chilled Sparkling
