Billi Quadra Sparkling Plus with XT Motion Dispenser & Mixer

by Billi

Download Add to collection

Description

The Quadra Sparkling is the ultimate in modern design and filtered drinking water appliances, delivering instant boiling and chilled filtered water, with the added luxury of sparkling water PLUS a separate sink mixer.

Requiring only cold feed mains supply, the Quadra Sparkling Plus mixes it’s own hot water without the need for any additional under-bench space requirements or boosters and utilises underbench ice bank technology to enhance capacity and recovery.

Dispenser design	XT Motion Dispenser
Mixer Design	Gooseneck, Paddle or Square Mixer
Capacity	Up to 100 Persons
Underbench Size	C&S 410mm h x 255mm w x 420mm d \| Boiling 340mm h x 180mm w x 465mm d
Product Code	Gooseneck: 906105MG
	Paddle: 906105MP
	Square: 906105MS
Water Combination	Boiling \| Chilled \| Plus \| Sparkling

Object Data

1 Revision

Last Updated

25/03/2026

Available Software

BSB

Compliant

EPD

Not Available

Accompanying literature

Product Data Sheet

Object metadata

Object

Parameter Type

_AuthorIH
_Authorized Bybimstore
_Bim Spec Guid0
_BS Bible Version17
_Created Byinfo@billi.com.au
_Current Revision0
_Distributed Bywww.bimstoreoz.au/
_Object User Guidewww.bimstoreoz.au/
120mm RiserNo
70mm RiserNo
Accessibility Performancen/a
Accessory Product Coden/a
Assembly CodeD2020
Asset TypeFixed
BIM Object NamePlumFixt_Assembly_Billi_QuadraSparklingPlus_XTMotion
Boiling Water Delivery220 cups per hour
CapacityUp to 120
Chilled Sparkling Water Delivery200 cups per hour
Classification NameUniclass2015
Classification ValuePr_40_70_23_42
Code Performancen/a
ColorBR - Brushed
Constituentsn/a
Created Byinfo@billi.com.au
Created On2026-04-01T09:00:00
Cups Per Hour NoteBased on a set volume of water being drawn every 30 seconds at an inlet temperature of average temperature 21°C. Each cup is equivalent to 170ml.
CW ConnectionYes
Default Elevation0 mm
DescriptionInstant boiling, chilled and sparkling filtered water system plus separate hot and cold mixer tap.
Dispenser DesignXT Motion Dispenser
Dispenser Height Adjustment0 mm
Documentation Certificateswww.billi.com.au/product/billi-quadra-sparkling-plus-15-xt-dispenser-and-gooseneck-mixer/
Documentation Installation Guidewww.billi.com.au/wp-content/uploads/2024/07/610014_Billi-Install-Guide_Quadra-Sparkling-Rev04.pdf
Documentation Literaturewww.billi.com.au/wp-content/uploads/2021/03/Billi-Oct-2024_Commercial-Brochure_Digital_FA.pdf
Documentation Maintenancewww.billi.com.au/product/billi-quadra-sparkling-plus-15-xt-dispenser-and-gooseneck-mixer/
Documentation Technicalwww.billi.com.au/product/billi-quadra-sparkling-plus-15-xt-dispenser-and-gooseneck-mixer/
Duration UnitYears
Expected Life0
FeaturesEnergy efficient. Adjustable chilled temperature. Adjustable sparkling level. HACCP certified. Eco intelligence technology. Ice Bank technology. BPA free.
Filter 1Filter : 5 Micron Fibron X
Filter 2Filter : 0.2 Micron Fibron XC
Filter 3Filter : HSD Fibron XT
Filter 4Filter : Sediment Only
Filter 5Filter : 0.2 Micron HF Sediment Only
FinishBrushed
FontNo
Font MaterialBilli_Metal_Brushed
Graden/a
HW ConnectionNo
Ifc Export AsIfcValve
Ifc Export TypeIfcValveTypeEnum.FAUCET
KeynoteN13
ManufacturerBilli
Manufacturer NameBilli
Materialn/a
Mixer TypePlumFixt_Billi_Mixer_Gooseneck : Standard
ModelBilli Quadra Sparkling Plus 15 with XT Motion Dispenser & Gooseneck Mixer
Model Number906105MGBR
Model ReferenceBilli Quadra Sparkling Plus 15 with XT Motion Dispenser & Gooseneck Mixer
NBS DescriptionInstant boiling and cold water taps
NBS Noten/a
NBS Object NameBilli - Instant boiling and cold water taps
NBS Office Master Tagn/a
NBS Reference90-15-35/485
Nominal Depth464 mm
Nominal Height340 mm
Nominal Length187 mm
Power SupplyA standard 10 amp power outlet plus an additional standard 15 amp outlet are required. Located no further than 1000mm from the underbench unit. The system is supplied with a 1 metre flex cord and plug
Production Year2026
Referenced Standardn/a
Replacement Costn/a
Riser Height0 mm
Riser MaterialBilli_Metal_Brushed
Shapen/a
Sizen/a
Spare Partsn/a
Tap MaterialBilli_Metal_Brushed
Type CommentsBilli Quadra Sparkling Plus 15 with XT Motion Dispenser & Gooseneck Mixer Brushed (906105MGBR)
Type NameBilli Quadra Sparkling Plus 15 with XT Motion Dispenser & Gooseneck Mixer Brushed (906105MGBR)
Underbench SizeC&S 410mm h x 255mm w x 420mm d Boiling 340mm h x 180mm w x 465mm d
Underbench Unit Depth464 mm
Underbench Unit Height340 mm
Underbench Unit Width187 mm
URLwww.billi.com.au/product/billi-quadra-sparkling-plus-15-xt-dispenser-and-gooseneck-mixer/
Vent ConnectionNo
Warranty DescriptionAll components of the drinking water systems are covered by a 36-month warranty.
Warranty Duration Labor3
Warranty Duration Parts3
Warranty Duration UnitYears
Warranty Guarantor Laborservice@billi.com.au
Warranty Guarantor Partsservice@billi.com.au
Waste ConnectionNo
Water TypeBoiling Chilled Sparkling
Worktop Cutter350 mm
