C-EL Electrically Operated Control Valve

Description

The FIREKILLTM C-EL Electrically Operated Control Valve is a series robust and reliable deluge, angle positioned, pilot controlled valves created entirely in Stainless Steel (316L) and designed for operating in open deluge systems as a zone valve or a full flooding/deluge valve, capable of functioning under harsh conditions and designed to be connected to systems where no corrosion is allowed.

This download from LPG Fire Australia contains the following size variations:

50mm Electrically Operated Control Valve
80mm Electrically Operated Control Valve

Object Data

1 Revision

Last Updated

31/08/2026

Available Software

BSB

Compliant

EPD

Not Available

Accompanying literature

Product Data Sheet

Object metadata

_AuthorIH
_Authorized Bybimstore
_Bim Spec Guid0
_BS Bible Version16
_Created Bywww.bimstoreoz.au/
_Current Revision1
_Distributed Bywww.bimstoreoz.au/
Accessibility Performancen/a
Assembly CodeD20
Asset TypeFixed
BIM Object NamePipeAccessories_FlangedElectricalControlValve_LPGFire_CEL
Classification NameUniclass2015
Classification ValuePr_65_54_30_22
Code Performancen/a
ColorSilver
Constituentsn/a
Created Byinfo@lpgfire.com.au
Created On2026-02-26T09:00:00
Default Elevation0 mm
DescriptionC-EL Electrically Operated Control Valve is a series of robust and reliable deluge, angle positioned, pilot controlled valves created entirely in Stainless Steel (316L) and designed for operating in open deluge systems as a zone valve or a full flooding/deluge valve.
Documentation Certificateslpgfire.com.au/
Documentation Installation Guidelpgfire.com.au/
Documentation Literaturelpgfire.com.au/
Documentation Maintenancelpgfire.com.au/
Documentation Technicallpgfire.com.au/
Duration UnitYears
Expected Life0
Factory Tested Pressure24 bar
Featuresn/a
Finishn/a
Graden/a
Ifc Export AsIfcValve
Ifc Export TypeUSERDEFINED
Lookup Table NamePipeAccessories_FlangedElectricalControlValve_LPGFire_CEL
Lookup Table Name FlangePipeAccessories_Flange_LPGFireAustralia_CEL
ManufacturerLPG Fire Australia
Manufacturer NameLPG Fire Australia
MaterialStainless Steel AISI 316L
ModelC-EL Electrically Operated Control Valve
Model ReferenceC-EL Electrically Operated Control Valve
NBS DescriptionDeluge valves
NBS Object NameLPG Fire Australia - Deluge valves
NBS Office Master Tagn/a
NBS Reference90-35-95/325
Primary MaterialLPGFireAustralia_StainlessSteel_AISI316L
Production Year2026
Referenced StandardTested in a ISO17025 certified test laboratory
Replacement Costn/a
ShapeCircular
SizeAvailable in 50mm and 80mm.
Spare Partsn/a
Type CommentsC-EL - 150 to 300
Type NameC-EL Electrically Operated Control Valve
URLlpgfire.com.au/
Warranty Descriptionn/a
Warranty Duration Labor0
Warranty Duration Parts0
Warranty Duration UnitYears
Warranty Guarantor Laborinfo@lpgfire.com.au
Warranty Guarantor Partsinfo@lpgfire.com.au
Working PressureMax 16 bar
