Cavity Wall Lintel - SX90

by Birtley Lintels

Download Add to collection

Description

Ultra heavy duty 90mm cavity wall lintel.

Object Data

1 Revision

Last Updated

07/11/2019

Available Software

EPD

Not Available

Accompanying literature

Object User Guide

Technical Data Sheet

Product Data Sheet

Object metadata

_AuthorAM
_Authorized Bybimstore
_Bim Spec Guid1
_BS Bible Version16
_Created Bywww.bimstore.co
_Current Revision1
_Distributed Bywww.bimstore.co
_Object User Guidewww.bimstore.co/products/cavity-wall-lintel-sx90/document/object-user-guide
Accessibility Performancen/a
Assembly CodeB20
Asset TypeFixed
BIM Object NameBirtleyGroup_SpecialtyEquipment_CavityWallLintel_SX90/130_(750-4200)
Classification NameUniclass 2015
Classification ValuePr_20_85_48_11
Code Performancen/a
Color65µm Hot Dip Galvanized to BS EN ISO 1461:2009
Constituentsn/a
Created Bylintel.technical@birtleygroup.co.uk
Created On2019-11-07 T09:00:00
Depth207 mm
DescriptionUltra heavy duty 90mm cavity wall lintel. We are the only lintel manufacturer to hot-dip galvanize after fabrication providing up to 50% more zinc protection than other approved coatings. Supergalv coating offers superior life expectancy. Post-fabrication galvanizing leaves no surface with inferior paint protection.
Documentation Certificateswww.birtleylintels.co.uk/
Documentation Installation Guidewww.birtleylintels.co.uk/
Documentation Literaturewww.birtleylintels.co.uk/
Documentation Maintenancewww.birtleylintels.co.uk/
Documentation Technicalwww.bimstore.co/products/cavity-wall-lintel-sx90/document/technical-data-sheet
Duration UnitYear
End Bearing150 mm
Expected Life0
Featuresn/a
Find A Stockistwww.birtleylintels.co.uk/stockist-locator
Finish65µm Hot Dip Galvanized to BS EN ISO 1461:2009
Fire Test60 mins (with 2 coat plaster finish)
Galvanised SteelS275JR to BS EN10025-2:2004 with 65 micron zinc coating hot dip galvanized post manufacture in accordance with BS EN ISO 1461:2009
Graden/a
Ifc Export AsIfcBeam
Ifc Export TypeIfcBeamTypeEnum.LINTEL
InsulationInsulation-Polystyrene
KeynoteL
ManufacturerBirtley Group
Manufacturer NameBirtley Group
MaterialMild Steel S275JR to BS EN10025-2:2004
Max Lintel Length4200 mm
Method For Assessment Of Loadn/a
Min Lintel Length750 mm
ModelSX90/130
Model NumberSX90/130 (750-4200)
Model ReferenceSX90/130
NBS DescriptionPrefabricated steel lintels
NBS Object NameBirtley Group - Prefabricated steel lintels
NBS Office Master Tagn/a
NBS Reference45-80-50/406
Nominal Depth280 mm
Nominal Height207 mm
Production Year2019
Referenced StandardEN846-9:2000/2016
Replacement Costn/a
Sales Emaillintel.sales@birtleygroup.co.uk
Sales Tel0191 411 2244
Shapen/a
Size750-4200
Spare Partsn/a
StandardDesigned in accordance with EN845-2:2013+A1:2016
SteelSteel, Galvanized
Technical Emaillintel.technical@birtleygroup.co.uk
Technical Tel0191 410 6631
Type CommentsSX90/130 (750-4200)
Type NameSX90/130 (750-4200)
U2 K GalvanisationS275JR with 150 micron zinc coating hot dip galvanized post manufacture in accordance with BS EN ISO 1461:2009
UDL0.00 kN
URLwww.birtleylintels.co.uk/
Warranty Descriptionn/a
Warranty Duration Labor0
Warranty Duration Parts0
Warranty Duration UnitYear
Warranty Guarantor Laborn/a
Warranty Guarantor Partslintel.sales@birtleygroup.co.uk
Weight Per M43.10 kg/m
Width280 mm

Sustainability & Environmental Data

Not available.

Environmental Product Declarations

There are no EPDs.
