Fig. 816W - Strainer - Ductile Iron (2026 onwards)

Description

FIG816W
Durable ductile iron body designed for water applications
Wafer type valve for compact and efficient system integration
Resilient liner ensures bubble-tight sealing performance
Anti-blow out stem design for enhanced safety
WRAS-approved epoxy coating for potable water use
Maintenance-free design reduces lifecycle costs
Suitable for flanges to BS EN 1092-2 PN16
Complies with BS EN593 requirements
Stainless steel shaft for strength and longevity

Object Data

1 Revision

Last Updated

11/06/2026

Available Software

BS1192:4

Compliant

BSB

Compliant

EPD

Not Available

Accompanying literature

Object User Guide

Product Data Sheet

Object metadata

_AuthorSM
_Authorized Bybimstore
_Bim Spec Guid0
_BS Bible Version17
_Created Bywww.bimstore.co/
_Current Revision1
_Distributed Bywww.bimstore.co/
_Object User Guidewww.bimstore.co/products/d47313fd-0672-449a-ab56-ffa193d72ee2/document/object-user-guide
12 HolesNo
16 HolesNo
20 HolesNo
4 HolesNo
8 HolesYes
A220 mm
Accessibility Performancen/a
Angle C50.00 °
Angled Piece Origin 1383 mm
Angled Piece Origin 2147 mm
Assembly CodeD20
Asset TypeFixed
B19 mm
BIM Object NameHattersley_Strainer_Fig816W
Body Plate Length158 mm
Body Plate Offset74 mm
Body Plate Thickness5 mm
Body Sec Rad78 mm
C156 mm
Classification NameUniclass 2015
Classification ValuePr_65_55_86_99
Code Performancen/a
ColorBlue
Connection Size100 mm
Connection Size Radius50 mm
Connector Size50 mm
Constituentsn/a
Created Byenquiries@Hattersley.com
Created On2026-03-31T:09:00:00
D3 mm
Default Elevation0 mm
DescriptionDN100
DN100
DN100Yes
DN125No
DN150No
DN200No
DN250No
DN300No
DN350No
DN400No
DN450No
DN50No
DN500No
DN600No
DN65No
DN80No
Documentation Certificateswww.bimstore.co/products/d47313fd-0672-449a-ab56-ffa193d72ee2/document/product-certificates
Documentation Installation Guidewww.bimstore.co/products/d47313fd-0672-449a-ab56-ffa193d72ee2/document/installation-guide
Documentation Literaturewww.bimstore.co/products/d47313fd-0672-449a-ab56-ffa193d72ee2/document/product-literature
Documentation Maintenancewww.bimstore.co/products/d47313fd-0672-449a-ab56-ffa193d72ee2/document/maintenance-information
Documentation Technicalwww.bimstore.co/products/d47313fd-0672-449a-ab56-ffa193d72ee2/document/technical-data-sheet
Drain Angle40.00 °
Drain Diameter119 mm
Drain Extension328 mm
Drain Flange Radius179 mm
Drain Plug Rad16 mm
Drain Sec Length253 mm
Drain Sec Radius59 mm
Duration UnitYear
E350 mm
Expected Life0
F251 mm
Featuresn/a
Finishn/a
Flange Hole Centres180 mm
Flange Hole Diameter19 mm
G350 mm
Graden/a
H32 mm
H Half16 mm
Ifc Export AsIfcValve
Ifc Export TypeIfcFilterTypeEnum.STRAINER
K Coefficient232
KeynoteS
Length312 mm
Length C211 mm
Loss MethodK Coefficient
ManufacturerHattersley
Manufacturer NameHattersley
Materialn/a
ModelFig 816W - Strainer - Ductile Iron
Model NumberFig 816W
Model ReferenceFig 816W - Strainer - Ductile Iron
NBS DescriptionY-type strainers
NBS Noten/a
NBS Object NameHattersley - Y-type strainers
NBS Office Master Tagn/a
NBS Reference90-20-80/320
Nominal Depth0 mm
Nominal Height0 mm
Nominal Length0 mm
Production Year2026
Referenced Standardn/a
Replacement Costn/a
Shapen/a
SizeDN100
Spare Partsn/a
Test Point Offset306 mm
Type CommentsDN100
Type NameDN100
URLwww.Hattersley.com/
Valve MaterialHattersley - Cast Iron - Blue
Warranty Descriptionn/a
Warranty Duration Labor0
Warranty Duration Parts0
Warranty Duration UnitYear
Warranty Guarantor Laborenquiries@Hattersley.com
Warranty Guarantor Partsenquiries@Hattersley.com
