ALLURE BRILLIANT PRIVATE COLLECTION Three-hole basin mixer 1/2″ L-Size (20667AL0)

by GROHE

Download Add to collection

Description

PRODUCT MAIN FEATURES:

ceramic headparts 1/2", 90°
knurled trapeze handles
GROHE Long-Life finish
GROHE Water Saving 5.0 l/min. flow limiter
spout with integrated mousseur
pop-up waste set 1 1/4"
pressure-proof, flexible connection hoses between spout and side valves
min. recommended pressure 1.0 bar

Object Data

1 Revision

Last Updated

25/09/2023

Available Software

BS1192:4

Compliant

BSB

Compliant

EPD

Not Available

Accompanying literature

Object User Guide

Product Data Sheet

Object metadata

_AuthorRW 156
_Authorized Bybimstore
_Bim Spec Guid0
_BS Bible Version17
_Created Bywww.bimstore.co/
_Current Revision1
_Distributed Bywww.bimstore.co/
_Object User Guidewww.bimstore.co/products/grohe-20667AL0/document/object-user-guide
Accessibility Performancen/a
Assembly CodeD2010
Asset TypeFixed
BIM Object NameGrohe_BasinMixer_AllureBrilliantPrivateCollection_20667AL0
Classification NameUniclass2015
Classification ValuePr_40_20_87_55
CO2 Neutral ProductionGROHE is one of the first leading manufacturer within the sanitary industry having a CO2-neutral production.
Code Performancen/a
ColorBrushed Hard Graphite
Constituentsn/a
Cradle To Cradle Certificationn/a
Created Byinfo-uk@grohe.com
Created On2023-05-04T09:00:00
Default Elevation0.0 mm
DescriptionALLURE BRILLIANT PRIVATE COLLECTION Basin Mixer
Dimensions Document Linkcdn.cloud.grohe.com/dimdraw/100000/100000/100000/100300/100320/100327/100327053/1280/100327053.jpg
Documentation Certificateswww.bimstore.co/products/grohe-20667AL0/document/product-certificates
Documentation Installation Guidewww.bimstore.co/products/grohe-20667AL0/document/installation-guide
Documentation Literaturewww.bimstore.co/products/grohe-20667AL0/document/product-literature
Documentation Maintenancewww.bimstore.co/products/grohe-20667AL0/document/maintenance-information
Documentation Technicalwww.bimstore.co/products/grohe-20667AL0/document/technical-data-sheet
Duration UnitYears
EcojoyNo
EF000003Top/tap hole
EF000139Other
EF002149FALSE
EF002286External thread
EF002671Other
EF007955FALSE
EF011775not applicable
EF011779FALSE
EF011781not applicable
EF0127535.00
EF014578false
EF014591false
EF015280false
EF016731Group I,<= 20 dB(A)
EF020075Yes
EF020105No
EF020780Two-grip
EF020781Top section, ceramic
EF0207851/2 inch
EF020787Group II, <=30 dB(A)
EF020789150.0 mm
EF020791Brass
EF020792FALSE
EF020794FALSE
EF020795Fixed
EF020796221.0 mm
EF020797152.0 mm
EF020798Waste unit
EF020799TRUE
EF020801FALSE
EF0218083-hole
EF021835200.0 mm
EF022042None
EF022168FALSE
EF022750Cast
EF023686not applicable
EF023687FALSE
EF023688Foam jet nozzle
EF025109Other
EFDE0022None
EFSE0002true
Expected Life0
Featuresn/a
Finishn/a
Full Recyclability Of PlasticAll plastic components are fully recyclable
Graden/a
GROHE Social Committmentgreen.grohe.com/social_engagement
GROHE Sustainabilitygreen.grohe.com
Ifc Export AsIfcPipeFitting
Ifc Export TypeIfcPipeFittingType
KeynoteN13
ManufacturerGrohe
Manufacturer NameGrohe
Materialn/a
ModelALLURE BRILLIANT PRIVATE COLLECTION Basin Mixer
Model Number20667AL0
Model ReferenceALLURE BRILLIANT PRIVATE COLLECTION Basin Mixer
NBS DescriptionMixer taps
NBS Noten/a
NBS Object NameGrohe - Mixer taps
NBS Office Master Tagn/a
NBS Reference45-35-70/345
Nominal Depth50.0 mm
Nominal Height221.0 mm
Nominal Length250.0 mm
Pipe MaterialGroheLimited-Pipework
PQ Diagram Linkn/a
Primary MaterialGrohe_BrushedHardGraphite
Product Descriptionceramic headparts 1/2", 90° knurled trapeze handles GROHE Long-Life Shine finish GROHE Water Saving 5.0 l/min flow limiter spout with integrated mousseur pop-up waste set 1 1/4" pressure-proof flexible connection hoses between spout and side valves min. recommended pressure 1.0 bar
Production Year2023
Product Number20667AL0
Product Page URLwww.grohe.co.uk/en_gb/-20667AL0.html
Product Short TextAllure Brilliant three hole basin mixer M-size brushed hard graphite w/ knurled trapeze handles
Product TypeTwo Handle Fitting
Referenced Standardn/a
Replacement Costn/a
Shapen/a
Sizen/a
Spare Partsinfo-uk@grohe.com
Sustainability Awardgreen.grohe.com/awards
Sustainability Reportgreen.grohe.com/reporting
TPI Document Linkn/a
Type CommentsALLURE BRILLIANT PRIVATE COLLECTION Basin Mixer
Type NameALLURE BRILLIANT PRIVATE COLLECTION Basin Mixer
URLwww.grohe.co.uk/
Warranty Descriptionn/a
Warranty Duration Labor0
Warranty Duration Parts0
Warranty Duration UnitYears
Warranty Guarantor Laborinfo-uk@grohe.com
Warranty Guarantor Partsinfo-uk@grohe.com

Sustainability & Environmental Data

Not available.

Environmental Product Declarations

There are no EPDs.
