ALLURE BRILLIANT Thermostatic shower mixer for 2 outlets with integrated shut off/diverter valve (24428AL0)

by GROHE

Download Add to collection

Description

Product Number - 24428AL0

EAN - 4005176795367

Colour - brushed hard graphite

PRODUCT MAIN FEATURES

knurled handle
set for final installation for
GROHE Rapido SmartBox 35 600/35 604
GROHE TurboStat compact cartridge with wax thermoelement
GROHE Long-Life finish
wall escutcheon with GROHE FastFixation(covered escutcheon- and shaft sealing, covered fixing)
metal escutcheon, retroactively 6° adjustable
printed head and hand shower symbol
GROHE SafeStop safety button at 38°C ( calibration required )
GROHE SafeStop Plus optional temperature limiter at 43°C or 46°C included
GROHE AquaDimmer, integrated shut off/diverter valve
flow performance: outlet B = 27 l/min outlet C = 30 l/min
without roughing-in-set

Product Page - https://www.grohe.co.uk/en_gb/Allure-Brilliant-Thermostatic-shower-mixer-for-2-outlets-with-integrated-shut-off-diverter-valve-24428AL0.html

Object Data

1 Revision

Last Updated

25/09/2023

Available Software

BS1192:4

Compliant

BSB

Compliant

EPD

Not Available

Accompanying literature

Object User Guide

Product Data Sheet

Object metadata

_AuthorRW 156
_Authorized Bybimstore
_Bim Spec Guid0
_BS Bible Version17
_Created Bywww.bimstore.co/
_Current Revision1
_Distributed Bywww.bimstore.co/
_Object User Guidewww.bimstore.co/products/grohe-24428AL0/document/object-user-guide
Accessibility Performancen/a
Assembly CodeD2010
Asset TypeFixed
BIM Object NameGrohe_ShowerMixerWithIntegratedShutOffDiverterValve_AllureBrilliant_24428AL0
Classification NameUniclass2015
Classification ValuePr_65_54_95_88
CO2 Neutral ProductionGROHE is one of the first leading manufacturer within the sanitary industry having a CO2-neutral production.
Code Performancen/a
ColorBrushed Hard Graphite
Constituentsn/a
Cradle To Cradle Certificationn/a
Created Byinfo-uk@grohe.com
Created On2023-05-04T09:00:00
Default Elevation0.0 mm
DescriptionALLURE BRILLIANT Shower Mixer With Integrated Shut Off Diverter Valve
Dimensions Document Linkn/a
Documentation Certificateswww.bimstore.co/products/grohe-24428AL0/document/product-certificates
Documentation Installation Guidewww.bimstore.co/products/grohe-24428AL0/document/installation-guide
Documentation Literaturewww.bimstore.co/products/grohe-24428AL0/document/product-literature
Documentation Maintenancewww.bimstore.co/products/grohe-24428AL0/document/maintenance-information
Documentation Technicalwww.bimstore.co/products/grohe-24428AL0/document/technical-data-sheet
Duration UnitYears
EcojoyNo
EF000003Surface mounting/built-under
EF000139Other
EF00170770 °C
EF002149TRUE
EF002286not applicable
EF002671Other
EF007955TRUE
EF011775EB
EF011779TRUE
EF01275327.00
EF014578not applicable
EF014591false
EF016731not applicable
EF020105Yes
EF020259Upward
EF020780Two-grip
EF020781Top section, ceramic
EF020785not applicable
EF020787Group II, <=30 dB(A)
EF020788false
EF020791Brass
EF020799TRUE
EF020805false
EF020967true
EF021035true
EF0218350.0 mm
EF021855false
EF022042C
EF0223371/2 inch
EF023686not applicable
EF023687FALSE
EF023688With hose connection
EF023957TRUE
EF024919true
EF025109Other
EFDE0022None
EFNL0001true
EFSE0002true
Expected Life0
Featuresn/a
Finishn/a
Full Recyclability Of PlasticAll plastic components are fully recyclable
Graden/a
GROHE Social Committmentgreen.grohe.com/social_engagement
GROHE Sustainabilitygreen.grohe.com
Ifc Export AsIfcPipeFitting
Ifc Export TypeIfcPipeFittingType
KeynoteN13
ManufacturerGrohe
Manufacturer NameGrohe
Materialn/a
ModelALLURE BRILLIANT Shower Mixer With Integrated Shut Off Diverter Valve
Model Number24428AL0
Model ReferenceALLURE BRILLIANT Shower Mixer With Integrated Shut Off Diverter Valve
NBS DescriptionThermostatic mixing valves
NBS Noten/a
NBS Object NameGrohe - Thermostatic mixing valves
NBS Office Master Tagn/a
NBS Reference90-10-90/370
Nominal Depth158.0 mm
Nominal Height50.0 mm
Nominal Length158.0 mm
Pipe MaterialGroheLimited-Pipework
PQ Diagram Linkn/a
Primary MaterialGrohe_BrushedHardGraphite
Product Descriptionknurled handle set for final installation for, GROHE Rapido SmartBox (35 600/35 604) GROHE TurboStat compact cartridge with wax thermoelement GROHE Long-Life Shine finish GROHE FastFixation escutcheon with covered shaft sealing and covered fixing metal escutcheon, retroactively 6° adjustable printed head and hand shower symbol GROHE SafeStop safety button at 38°C GROHE SafeStop Plus optional temperature limiter at 43°C or 46°C included GROHE AquaDimmer, integrated shut off/diverter valve flow performance: outlet B = 27 l/min outlet C = 30 l/min without roughing-in set
Production Year2023
Product Number24428AL0
Product Page URLwww.grohe.co.uk/en_gb/-24428AL0.html
Product Short TextGrohtherm Cube Thermostatic shower mixer for 2 outlets brushed hard graphite knurled handle
Product TypeThermostat
Referenced Standardn/a
Replacement Costn/a
Shapen/a
Sizen/a
Spare Partsinfo-uk@grohe.com
Sustainability Awardgreen.grohe.com/awards
Sustainability Reportgreen.grohe.com/reporting
TPI Document Linkn/a
Type CommentsALLURE BRILLIANT Shower Mixer With Integrated Shut Off Diverter Valve
Type NameALLURE BRILLIANT Shower Mixer With Integrated Shut Off Diverter Valve
URLwww.grohe.co.uk/
Warranty Descriptionn/a
Warranty Duration Labor0
Warranty Duration Parts0
Warranty Duration UnitYears
Warranty Guarantor Laborinfo-uk@grohe.com
Warranty Guarantor Partsinfo-uk@grohe.com

Sustainability & Environmental Data

Not available.

Environmental Product Declarations

There are no EPDs.
