GROHTHERM SMARTCONTROL Thermostat for concealed installation with 2 valves (29119DL0)

by GROHE

Download Add to collection

Description

set for final installation for GROHE Rapido SmartBox (35 600/35 604)
metal wall escutcheon with GROHE FastFixation
(covered escutcheon and shaft sealing, covered
fixing), retroactively 6° adjustable
GROHE StarLight finish
GROHE SmartControl push for ON-OFF, turn for volume adjustment from EcoJoy to Full Flow, exchangeable symbols
GROHE TurboStat compact cartridge with wax thermoelement
GROHE SafeStop safety button at 38°C
GROHE SafeStop Plus optional temperature limiter at 43°C or 46°C included
built-in non return valves and dirt strainers
multiple outlets can be run simultaneously
without roughing-in set
flow performance:
outlet B = 24 l/min
outlet C = 26 l/min
outlet B+C = 29 l/min

Object Data

1 Revision

Last Updated

16/12/2021

Available Software

BS1192:4

Compliant

BSB

Compliant

EPD

Not Available

_AuthorAM
_Authorized Bybimstore
_Bim Spec Guid0
_BS Bible Version16
_Created Bywww.bimstore.co
_Current Revision1
_Distributed Bywww.bimstore.co
_Object User Guidewww.bimstore.co/products/grohe-grohtherm-smartcontrol-thermostat-29119dl0/document/object-user-guide
Accessibility Performancen/a
Assembly CodeD2010
Asset TypeFixed
BIM Object NameGrohe_PlumbingFixtures_GrohthermSmartControl_TwoValveThermostat_29119DL0
Classification NameUniclass2015
Classification ValuePr_65_54_95_88
CO2 Neutral ProductionGROHE is one of the first leading manufacturer within the sanitary industry having a CO2-neutral production.
Code Performancen/a
ColorOther
Constituentsn/a
Cradle To Cradle Certificationn/a
Created Byinfo-uk@grohe.com
Created On2021-12-07 T:09:00:00
CW ConnectionNo
Default Elevation800.0 mm
Descriptionset for final installation for GROHE Rapido SmartBox (35 600/35 604) metal wall escutcheon with GROHE FastFixation (covered escutcheon and shaft sealing, covered fixing), retroactively 6° adjustable GROHE StarLight finish GROHE SmartControl push for ON-OFF, turn for volume adjustment from EcoJoy to Full Flow, exchangeable symbols GROHE TurboStat compact cartridge with wax thermoelement GROHE SafeStop safety button at 38°C GROHE SafeStop Plus optional temperature limiter at 43°C or 46°C included built-in non return valves and dirt strainers multiple outlets can be run simultaneously without roughing-in set flow performance: outlet B = 24 l/min outlet C = 26 l/min outlet B+C = 29 l/min
Dimensions Document Linkcdn.cloud.grohe.com/dimdraw/2000/2000/2060/2065/2065553/1280/2065553.jpg
Documentation Certificateswww.bimstore.co/products/grohe-grohtherm-smartcontrol-thermostat-29119dl0/document/product-certificates
Documentation Installation Guidewww.bimstore.co/products/grohe-grohtherm-smartcontrol-thermostat-29119dl0/document/installation-guide
Documentation Literaturewww.bimstore.co/products/grohe-grohtherm-smartcontrol-thermostat-29119dl0/document/product-literature
Documentation Maintenancewww.bimstore.co/products/grohe-grohtherm-smartcontrol-thermostat-29119dl0/document/maintenance-information
Documentation Technicalwww.bimstore.co/products/grohe-grohtherm-smartcontrol-thermostat-29119dl0/document/technical-data-sheet
Duration UnitYear
EcojoyNo
EF000010EV022195
EF002149Yes
EF002286Insert (push coupling)
EF002671Other
EF0054640
EF011775EB
EF011779Yes
EF01275329.0
EF020105Yes
EF020780Single-grip
EF020781Other
EF020782Brass
EF020783Other
EF020784Other
EF020785M26 x 1.5
EF0207862
EF020787Group I,<= 20 dB(A)
EF0207890.0 mm
EF02182729.0
EF022042C
EF023686Aluminium
EF023687No
EF023957Yes
EFDE0022Group I, <=20 dB(A)
Expected Life0
Featuresn/a
Finishn/a
Full Recyclability Of PlasticAll plastic components are fully recycable
Graden/a
GROHE Social Committmentgreen.grohe.com/social_engagement
GROHE Sustainabilitygreen.grohe.com
HW ConnectionNo
Ifc Export AsIfcPipeFitting
Ifc Export TypeIfcPipeFittingType
Installation Videon/a
KeynoteN13
ManufacturerGrohe
Manufacturer NameGrohe
MaterialBrass
Model29119DL0
Model Number29119DL0
Model ReferenceThermostat for concealed installation with 2 valves
NBS DescriptionThermostatic mixing valves
NBS Noten/a
NBS Object NameGrohe - Thermostatic mixing valves
NBS Office Master Tagn/a
NBS Reference90-10-90/370
Nominal Depth0.0 mm
Nominal Height0.0 mm
Nominal Length0.0 mm
PQ Diagram Linkcdn.cloud.grohe.com/PQCharts/lores/2/291/original/29119DL0-pqchart-en_GB.svg
Primary MaterialGrohe - Metal - Brushed Warm Sunset
Product Descriptionset for final installation for GROHE Rapido SmartBox (35 600/35 604) metal wall escutcheon with GROHE FastFixation (covered escutcheon and shaft sealing, covered fixing), retroactively 6° adjustable GROHE StarLight finish GROHE SmartControl push for ON-OFF, turn for volume adjustment from EcoJoy to Full Flow, exchangeable symbols GROHE TurboStat compact cartridge with wax thermoelement GROHE SafeStop safety button at 38°C GROHE SafeStop Plus optional temperature limiter at 43°C or 46°C included built-in non return valves and dirt strainers multiple outlets can be run simultaneously without roughing-in set flow performance: outlet B = 24 l/min outlet C = 26 l/min outlet B+C = 29 l/min
Production Year2021
Product Number29119DL0
Product Short TextThermostat for concealed installation with 2 valves Thermostat
Product TypeThermostat
Referenced Standardn/a
Replacement Costn/a
Shapen/a
Sizen/a
Spare Partsn/a
Sustainability Awardgreen.grohe.com/awards
Sustainability Reportgreen.grohe.com/reporting
TPI Document Linkcdn.cloud.grohe.com/tpi/100000/100000/100000/100100/100150/100159/100159269/original/100159269.pdf
Type CommentsThermostat for concealed installation with 2 valves
Type NameThermostat for concealed installation with 2 valves
URLwww.grohe.co.uk/en_gb/
Vent ConnectionNo
Warranty Descriptionn/a
Warranty Duration Labor0
Warranty Duration Parts0
Warranty Duration UnitYear
Warranty Guarantor Laborinfo-uk@grohe.com
Warranty Guarantor Partsinfo-uk@grohe.com
Waste ConnectionNo
