Two Part Industrial Drain 200mm - Tile / Resin / Concrete
by BLÜCHER®
Description
Drains & Upper Parts with Square Top (774.402.000) or Circular Top (774.502.000) : No membrane
Square Top (774.402.000)
- Floor: concrete and tiled
- Frame: 200x200mm
- Stainless steel: AISI304/EN1.4301
Circular Top (774.502.000)
- Floor: resin
- Frame: Ø205mm
- Stainless steel: AISI304/EN1.4301
Select the product(s) based on outside (visible) dimension, flow rate, and / or item number, to upload in your project.
- Horizontal and Vertical outlet, height adjustable, 75 and 110 mm
- With and without membrane and for concrete, tiled and resin floors.
Upper part models Square 774.402 and Round 774.502
Lower part models 760.002 / 760.160. / 763.002 / 763.042 / 769 / 771 / 774 / 775
- The product is made from 1.5 mm acid-pickled stainless steel.
- 4 Grating options load class up to 7.000 kg
- Designed in accordance with EN1253.
Key Component Features:
- User selectable Drain
- User selectable Gratings
- User selectable Lower Parts
- User selectable Watertrap
- User selectable Filter Basket
- 360 degree Lower Part
- Height adjustment
- Automated product codes
- Pre-selected concrete cut out / base concrete slab option for installation purpose
Products: 774.402.000, 774.502.000
Search Opt.: blucher
Read moreObject Data
1 Revision
Last Updated
26/06/2023
Available Software
BS1192:4
Compliant
BSB
Compliant
EPD
Not Available
Sustainability & Environmental Data
Not available.
Environmental Product Declarations
Environmental Product Declaration (EPD)
Valid until 2nd Dec 2030
