KOMFORT EC D5B 180 - Heat Recovery Unit

by Blauberg

Download Add to collection

Description

Air handling units for efficient supply and exhaust ventilation in flats, houses, cottages and other buildings.

ERP 2018 Compliant

Low Energy EC Motors

Objects included:

KOMFORT EC D5B 180 S21

Object Data

1 Revision

Last Updated

15/09/2021

Available Software

BS1192:4

Compliant

BSB

Compliant

EPD

Not Available

Accompanying literature

Installation Guide

Product Literature

Technical Data Sheet

Product Data Sheet

Object metadata

_Authortechnicalsupport@blauberg.co.uk
_Authorized Bybimstore
_Bim Spec Guid0
_BS Bible Version16
_Created ByBlauberg UK
_Current Revision1
_Distributed Bywww.bimstore.co/
_Object User Guidewww.bimstore.co/products/komfort-ec-d5-180-s21/document/object-user-guide
A1009 mm
A1900 mm
Accessibility Performancen/a
Asset TypeFixed
B600 mm
B1326 mm
B2163 mm
BIM Object Nameblauberg_MechanicalEquipment_Komfort_EC_D5D1802
Casing MaterialPolypropylene Black
Classification NameUniclass2015
Classification ValuePr_60_65_03_86
Code Performancen/a
Colorn/a
Constituentsn/a
Created Bytechnicalsupport@blauberg.co.uk
Created On2021-08-31T09:00:00
Current1 A
D150 mm
Ddrain20 mm
DescriptionAir Handling Unit
Documentation Certificateswww.bimstore.co/products/komfort-ec-d5-180-s21/document/product-certificates
Documentation Installation Guidewww.bimstore.co/products/komfort-ec-d5-180-s21/document/installation-guide
Documentation Literaturewww.bimstore.co/products/komfort-ec-d5-180-s21/document/product-literature
Documentation Maintenancewww.bimstore.co/products/komfort-ec-d5-180-s21/document/maintenance-information
Documentation Technicalwww.bimstore.co/products/komfort-ec-d5-180-s21/document/technical-data-sheet
Drain Connection Diameter19 mm
Drain Pipe 1Yes
Drain Pipe 2Yes
Duct Connection Diameter150 mm
Duct Con L55 mm
Duration UnitYears
Expected Life0
Extract Air FilterG4
Featuresn/a
Finishn/a
Front Maintenance Zone Height600 mm
Front Maintenance Zone Length900 mm
Front Maintenance Zone Width600 mm
Graden/a
H264 mm
H1250 mm
H2110 mm
Heat Exchanger Materialpolystyrene
Heat Exchanger Typecounter-flow
Heatrecoveryefficiency Percentage86..98
Ifc Export AsIfcEnergyConversionDeviceType
Ifc Export TypeIfcUnitaryEquipmentTypeEnum.AIRCONDITIONINGUNIT
Load ClassificationHVAC
Maintenance Zone MaterialMaintenance Zone
ManufacturerBlauberg
Manufacturer NameBlauberg UK
Materialn/a
Maximum Air Flow220 m³/h
Metal MaterialMetal Zinc
ModelKOMFORT EC D5B 180 S21
Model NumberKomfort EC D5D1802
Model ReferenceKOMFORT EC D5B 180 S21
NBS DescriptionSupply air handling units
NBS Object NameBlauberg UK - Air Handling Units
NBS Office Master Tagn/a
NBS Reference90-45-15/310
Nominal Depth0 mm
Nominal Height0 mm
Nominal Length0 mm
Number Of Poles1
Power87 W
Power Factor1
Production Year2021
Referenced Standardn/a
Replacement Costn/a
RP Mmin 12200
SEC ClassA+
Shapen/a
Side Maintenance Zone Height350 mm
Side Maintenance Zone Length900 mm
Side Maintenance Zone Width250 mm
Sizen/a
Sound Pressure Levelat 3m DBA33
Spare Partsn/a
Supply Air FilterG4+F7
Transported Air Temperature Degrees C–25 …+40
Type CommentsAir Handling Unit KOMFORT EC D5B 180 S21
Type NameAir Handling Unit KOMFORT EC D5B 180 S21
URLblaubergventilatoren.de/en/series/komfort-ec-d5b180-e
Voltage230 V
Warranty Descriptionn/a
Warranty Duration Labor0
Warranty Duration Parts0
Warranty Duration UnitYears
Warranty Guarantor Laborn/a
Warranty Guarantor Partstechnicalsupport@blauberg.co.uk
Weight14.00 kg
