Manifold for Inert Gas System 400 Series

by LPG Fire Australia

Download Add to collection

Description

The back-plate manifold provides pressure reduction valve so that manifold pressure can be used to operate selector valve solenoids.

This download from LPG Fire Australia contains the following size variations:

Manifold 2 Area - 01-3508-0002
Manifold 3 Area - 01-3508-0003
Manifold 4 Area - 01-3508-0004
Manifold 5 Area - 01-3508-0005

Object Data

1 Revision

Last Updated

31/08/2026

Available Software

BSB

Compliant

EPD

Not Available

Accompanying literature

Product Data Sheet

Object metadata

_AuthorIH
_Authorized Bybimstore
_Bim Spec Guid0
_BS Bible Version16
_Created Bywww.bimstoreoz.au/
_Current Revision1
_Distributed Bywww.bimstoreoz.au/
2nd ValveNo
3rd ValveNo
4th ValveNo
Accessibility Performancen/a
Assembly CodeD20
Asset TypeFixed
Back Plate Thickness20 mm
BIM Object NamePipeAccessories_Manifold_LPGFire_InertGasSystem400
Box Height50 mm
Box Offset58 mm
Box Width25 mm
Classification NameUniclass2015
Classification ValuePr_65_54_30_34
Code Performancen/a
Colorn/a
Constituentsn/a
Created Byinfo@lpgfire.com.au
Created On2026-02-17T09:00:00
Default Elevation0 mm
DescriptionThe back-plate manifold provides pressure reduction valve so that manifold pressure can be used to operate selector valve solenoids.
Documentation Certificateslpgfire.com.au/
Documentation Installation Guidelpgfire.com.au/
Documentation Literaturelpgfire.com.au/
Documentation Maintenancelpgfire.com.au/
Documentation Technicallpgfire.com.au/
Duration UnitYears
End Valve305 mm
Expected Life0
Featuresn/a
Finishn/a
Graden/a
Ifc Export AsIfcValve
Ifc Export TypeDIVERTING
ManufacturerLPG Fire Australia
Manufacturer NameLPG Fire Australia
Materialn/a
ModelInert Gas System 400 Series
Model Number01-3508-0002
Model ReferenceInert Gas System 400 Series
NBS DescriptionGas fire suppression manifolds
NBS Object NameLPG Fire Australia - Gas fire suppression manifolds
NBS Office Master Tagn/a
NBS Reference90-35-35/420
Nominal Diameter6 mm
Nominal Height200 mm
Nominal Length650 mm
Number Area2
Primary MaterialLPGFireAustralia_AluminumBody
Production Year2026
Referenced Standardn/a
Replacement Costn/a
Secondary MaterialLPGFireAustralia_Copper
Second Post306 mm
Second Valve305 mm
ShapeRectangular
Sizen/a
Spare Partsn/a
Starting Post270 mm
Starting Valve200 mm
System Height200 mm
System Width650 mm
Tertiary MaterialLPGFireAustralia_Brass
Type Comments01-3508-0002
Type NameInert Gas System 400 Series
URLlpgfire.com.au/
Valve W165 mm
Valve W221 mm
Warranty Descriptionn/a
Warranty Duration Labor0
Warranty Duration Parts0
Warranty Duration UnitYears
Warranty Guarantor Laborinfo@lpgfire.com.au
Warranty Guarantor Partsinfo@lpgfire.com.au
