DescriptionThermostatic Mixing Valves (TMV) are self-acting and designed to blend hot and cold water, to ensure a constant, safe outlet temperature and prevent scalding.
FeaturesA self-acting Thermostatic Mixing Valve designed to blend hot and cold water, to ensure a constant, controlled safe outlet temperature. Fulfils the ‘duty of care’ requirements against scalding.Ideal for healthcare, schools, workplace and domestic environments. Flat face union ensures easy removal for maintenance. Integral strainers and check valves. Tamper-proof adjustment. WRAS Approved maximum operating temperature 85°C.
Finishn/a
Graden/a
Ifc Export AsIfcValve
Ifc Export TypeIfcValveTypeEnum.REGULATING
IR15 mm
KeynoteS
LH28 mm
ManufacturerCrane Fluid Systems
Manufacturer NameCrane Fluid Systems
MaterialDZR Brass
MH22 mm
ModelThermostatic Mixing Valves
Model NumberD1088
Model ReferenceThermostatic Mixing Valves
NBS DescriptionThermostatic mixing valves
NBS Noten/a
NBS Object NameCrane - Thermostatic mixing valves
NBS Office Master Tagn/a
NBS Reference90-10-90/370
Nominal Depth39 mm
Nominal Height116 mm
Nominal Length134 mm
Production Year2026
R21 mm
RedPVC, Maroon
Referenced Standardn/a
Replacement Costn/a
SH17 mm
Shapen/a
SizeDN15
Spare Partsn/a
Type CommentsDN15 - D1088
Type IFC Predefined TypeIfcValveTypeEnum.REGULATING
