INTRAform DM - Entrance Matting

by INTRAsystems

Download Add to collection

Description

Heavy-duty aluminium entrance matting with extra-wide fibre inserts for optimum moisture absorption in high traffic areas.

Compatible with our standard INTRAform system
Interlocking sections for ease of installation and seamless design
Suitable for all fibre insert ranges

Object Data

1 Revision

Last Updated

02/03/2020

Available Software

BS1192:4

Compliant

BSB

Compliant

EPD

Not Available

Accompanying literature

Object User Guide

Product Literature

Product Data Sheet

Object metadata

_AuthorJack Yellop
_Authorized Bybimstore
_Bim Spec Guid0
_BS Bible Version16
_Created Bywww.bimstore.co.uk
_Current Revision1
_Distributed Bywww.bimstore.co.uk
_Object User Guidewww.bimstore.co/product/files/documents/2019/04/12/intrasystems-userguide-v11.pdf
Accessibility Performancen/a
ArrangementInsert Internal
Assembly CodeE2010
Asset TypeFixed
Base ColourAnodised to any RAL colour Anodised to any RAL colour Anodised to any RAL colour Anodised to any RAL colour
Base MaterialAluminium Aluminium Aluminium
BIM Object NameINTRASystems_EntranceMatting_INTRAFormDM
Classification NameUniclass2015
Classification ValuePr_35_57_11_26
Code Performancen/a
ColorAluminium
Constituents100% recycled Aluminium plank system with choice of rubber, polyamide or polypropylene inserts.
ConstructionClosed
Created Byinfo@intrasystems.co.uk
Created On2019-03-11T09:00:00
Default Elevation1219 mm
DescriptionHeavy duty aluminium Entrance Matting with extra wide fibre inserts for optimum moisture absorption in high traffic areas.
Documentation Certificatesn/a
Documentation Installation Guiden/a
Documentation Literaturewww.bimstore.co/products/intraformdm-entrance-matting/document/product-literature
Documentation Maintenancen/a
Documentation Technicaln/a
Duration UnitYears
Environmental Product Declaration100% Recycled aluminium
Expected Life15
FeaturesHeavy Duty aluminium Plank System / Optimum moisture absorption from extra width fibre inserts / Interlocking sections for ease of installation and seamless design./ Compatible with standard INTRAform system / 100% recycled aluminium / Suitable for all fibre insert ranges / Exceptional durability and performance.
FinishAluminium
Graden/a
Height17 mm
Ifc Export AsIfcCovering IfcCovering IfcCovering
Ifc Export TypeIfcCoveringTypeEnum.FLOORING
Insert Colour OptionsElite polyamide - 608 Black, 607 Anthracite, 606 Grey, 602 Blue, 605 Brown, 609 Purple, 610 Turquoise, 604 Coco, 601 Red. Premier polyamide - 007 Anthracite, 014 Grey. Polypropylene - 443 Anthracite, 451 Grey.
Integral AccessoriesPolypropylene ribbed fibre (colour)/ polyamide fibre (colour) or combination of inserts.
KeynoteM50
Linking Jointsn/a
ManufacturerINTRAsystems
Manufacturer NameINTRAsystems
MaterialHeavy Duty Aluminium
Matting Height16.5mm
Matwell Frame FinishClear anodized as standard. Anodized finish in any RAL colour available to special order.
ModelINTRAform DM
Model Numbern/a
Model ReferenceINTRAform DM
Module Width66.4mm
NBS DescriptionEntrance matting
NBS Noten/a
NBS Object NameINTRASystems,Entrance matting
NBS Office Master Tagn/a
NBS Reference45-35-35/420
Nominal Depth0 mm
Patternn/a
Production Year2019
Radiusn/a
Referenced Standardn/a
Replacement Costn/a
Rubber MaterialIntraSytems_RubberMaterial_Rubber
ShapeRectangular
Sizen/a
Spare Partsn/a
Surface Insert OptionsPolyamide fibre, Polypropylene fibre.
Temperature ResistanceAluminium resistance: -50°C to +90°C.
Traffic TypeHeavy / Extreme
Type CommentsRecessed Entrance Mat System
Type NameINTRAform DM
URLwww.intrasystems.co.uk/products/intraform-dm/
Warranty Description10 Performance Guarantee, subject to correct cleaning and maintenance procedures being carried out
Warranty Duration Laborn/a
Warranty Duration Partsn/a
Warranty Duration UnitYears
Warranty Guarantor Laborwww.intrasystems.co.uk/products/intraform-dm/
Warranty Guarantor Partswww.intrasystems.co.uk/products/intraform-dm/
Weight18.4kg/m²

Sustainability & Environmental Data

Not available.

Environmental Product Declarations

There are no EPDs.
